Android入门笔记之标签布局（Tab Layout）

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
<?xml version="1.0" encoding="UTF-8"?>
<FrameLayout xmlns:android="http://schemas.android.com/apk/res/android"
    android:layout_width="fill_parent"
    android:layout_height="fill_parent"
    android:orientation="vertical"
    >


    <LinearLayout
        android:id="@+id/tab1"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:orientation="vertical" >

        <TextView
            android:id="@+id/tabtext1"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="1" />

    </LinearLayout>

    <LinearLayout
        android:id="@+id/tab2"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:orientation="vertical" >

    <TextView
            android:id="@+id/tabtext2"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="2" />

    </LinearLayout>

    <LinearLayout
        android:id="@+id/tab3"
        android:layout_width="match_parent"
        android:layout_height="match_parent"
        android:orientation="vertical" >

        <TextView
            android:id="@+id/tabtext3"
            android:layout_width="wrap_content"
            android:layout_height="wrap_content"
            android:text="3" />

    </LinearLayout>

</FrameLayout>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
package com.ui.tab;

import android.app.TabActivity;
import android.os.Bundle;
import android.view.LayoutInflater;
import android.widget.TabHost;
import android.widget.TextView;
import android.widget.TabHost.OnTabChangeListener;
import android.widget.TabHost.TabSpec;

import com.test.R;

public class MyTabActivity extends TabActivity implements OnTabChangeListener{

	/**
	 * @ProjectName:  [androidtest]
	 * @Package:      [com.ui.tab.TabActivity.java]
	 * @ClassName:    [TabActivity]
	 * @Description:
	 * @Author:       [gmj]
	 * @CreateDate:   [2013-8-30 下午2:39:50]
	 * @Version:      [v1.0]
	 */
	@Override
	public void onCreate(Bundle savedInstanceState)
	{
		super.onCreate(savedInstanceState);
		TabHost tabhost = this.getTabHost();
		LayoutInflater.from(this).inflate(R.layout.activity_tab, tabhost.getTabContentView() , true);
		TabSpec tabA = tabhost.newTabSpec("A").setIndicator("AAA" , this.getResources().getDrawable(R.drawable.img1)).setContent(R.id.tab1);
		tabhost.addTab(tabA);
		TabSpec tabB = tabhost.newTabSpec("B").setIndicator("BBB" , this.getResources().getDrawable(R.drawable.img2)).setContent(R.id.tab2);
		tabhost.addTab(tabB);
		TabSpec tabC = tabhost.newTabSpec("C").setIndicator("CCC" , this.getResources().getDrawable(R.drawable.img3)).setContent(R.id.tab3);
		tabhost.addTab(tabC);
		tabhost.setOnTabChangedListener(this);
		onTabChanged("A");//预先设置为A分页
	}

	@Override
	public void onTabChanged(String arg0) {
		// TODO Auto-generated method stub
		if(arg0.equals("A")){
			TextView tv = (TextView)findViewById(R.id.tabtext1);
			tv.setText("123456");
		}
		if(arg0.equals("B")){
			TextView tv2 = (TextView)findViewById(R.id.tabtext2);
			tv2.setText("abcdef");
		}
		if(arg0.equals("C")){
			TextView tv3 = (TextView)findViewById(R.id.tabtext3);
			tv3.setText("ghjkl");
		}
	}
}
