 * epfd 为epoll_create创建的fd
 * op 是我们的操作种类 增删改 ADD DEL MOD
 * fd 当然是我们要加入的fd了
 * event 我们所关心的事件类型 注意只有我们注册的事件才会在epoll_wait被唤醒后传递到用户空间 否则虽然内核可以收到 但不会传递到用户空间
 */
SYSCALL_DEFINE4(epoll_ctl, int, epfd, int, op, int, fd,
		struct epoll_event __user *, event)
{
	int error;
	int did_lock_epmutex = 0;
	struct file *file, *tfile;
	struct eventpoll *ep;
	struct epitem *epi;
	struct epoll_event epds;

	error = -EFAULT;
	/*
	static inline int ep_op_has_event(int op)
	{
		return op != EPOLL_CTL_DEL; // DEL的时候当然不用从用户态拷贝event啦
	}
*/
	if (ep_op_has_event(op) && //我们可以在上面看到ep_op_has_event的函数体 用以判断是否需要从用户态拷贝数据
	    copy_from_user(&epds, event, sizeof(struct epoll_event))) //从用户空间把数据拷贝过来
		goto error_return;

	/* Get the "struct file *" for the eventpoll file */
	error = -EBADF;
	file = fget(epfd); //得到epoll的file指针
	if (!file)
		goto error_return;

	/* Get the "struct file *" for the target file */
	tfile = fget(fd); //得到要添加fd的file指针
	if (!tfile)
		goto error_fput;

	/* The target file descriptor must support poll */
	error = -EPERM;
	if (!tfile->f_op || !tfile->f_op->poll) //如果要监听的fd不支持poll的话就没办法了 只能报error了.
		goto error_tgt_fput;

	/*
	 * We have to check that the file structure underneath the file descriptor
	 * the user passed to us _is_ an eventpoll file. And also we do not permit
	 * adding an epoll file descriptor inside itself.
	 */
	error = -EINVAL;
	/*
/*
static inline int is_file_epoll(struct file *f)
{
	return f->f_op == &eventpoll_fops; //更快的检测fd是否为一个epoll_fd
}
*/
	if (file == tfile || !is_file_epoll(file)) //当然不允许自己监听自己了,同时得保证epfd是一个epoll的fd
		goto error_tgt_fput;

	/*
	 * At this point it is safe to assume that the "private_data" contains
	 * our own data structure.
	 */
	ep = file->private_data; //上一篇说到private_data中存的是分配好的eventpoll

	/*
	 * When we insert an epoll file descriptor, inside another epoll file
	 * descriptor, there is the change of creating closed loops, which are
	 * better be handled here, than in more critical paths.
	 *
	 * We hold epmutex across the loop check and the insert in this case, in
	 * order to prevent two separate inserts from racing and each doing the
	 * insert "at the same time" such that ep_loop_check passes on both
	 * before either one does the insert, thereby creating a cycle.
	 */
	if (unlikely(is_file_epoll(tfile) && op == EPOLL_CTL_ADD)) { //防止epoll插入到另一个epoll中
		mutex_lock(&epmutex);
		did_lock_epmutex = 1;
		error = -ELOOP;
		if (ep_loop_check(ep, tfile) != 0)
			goto error_tgt_fput;
	}


	mutex_lock(&ep->mtx); //对fd进行操作时上mtx这把锁

	/*
	 * Try to lookup the file inside our RB tree, Since we grabbed "mtx"
	 * above, we can be sure to be able to use the item looked up by
	 * ep_find() till we release the mutex.
	 */
	epi = ep_find(ep, tfile, fd); //O(logn)查询要操作的fd是否已经存在
	/*
		static inline void ep_set_ffd(struct epoll_filefd *ffd,
					      struct file *file, int fd) //创建一个进行比较的项
		{
			ffd->file = file;
			ffd->fd = fd;
		}


		static inline int ep_cmp_ffd(struct epoll_filefd *p1,
					     struct epoll_filefd *p2)
		{
			return (p1->file > p2->file ? +1:
			        (p1->file < p2->file ? -1 : p1->fd - p2->fd));
		}
		//从RB-tree中寻找期望插入的fd是否存在
		static struct epitem *ep_find(struct eventpoll *ep, struct file *file, int fd)
		{
			int kcmp;
			struct rb_node *rbp;
			struct epitem *epi, *epir = NULL;
			struct epoll_filefd ffd;

			ep_set_ffd(&ffd, file, fd);
			for (rbp = ep->rbr.rb_node; rbp; ) {
				epi = rb_entry(rbp, struct epitem, rbn);
				kcmp = ep_cmp_ffd(&ffd, &epi->ffd); //红黑树的排序规则
				if (kcmp > 0)
					rbp = rbp->rb_right;
				else if (kcmp < 0)
					rbp = rbp->rb_left;
				else {
					epir = epi;
					break;
				}
			}
			return epir; //如果找到返回找到的fd所对应的节点
		}
	*/

	error = -EINVAL;
	switch (op) {
	case EPOLL_CTL_ADD:
		if (!epi) {
			epds.events |= POLLERR | POLLHUP; //我们可以看到这两个事件显然我们也没有必要注册
			error = ep_insert(ep, &epds, tfile, fd);
		} else
			error = -EEXIST;
		break;
	case EPOLL_CTL_DEL:
		if (epi)
			error = ep_remove(ep, epi);
		else
			error = -ENOENT;
		break;
	case EPOLL_CTL_MOD:
		if (epi) {
			epds.events |= POLLERR | POLLHUP;
			error = ep_modify(ep, epi, &epds);
		} else
			error = -ENOENT;
		break;
	}
	mutex_unlock(&ep->mtx);

error_tgt_fput:
	if (unlikely(did_lock_epmutex))
		mutex_unlock(&epmutex);

	fput(tfile); //正常关闭文件
error_fput:
	fput(file);
error_return:

	return error;
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
//注意 这个整个函数调用都是上锁的
static int ep_insert(struct eventpoll *ep, struct epoll_event *event,
		     struct file *tfile, int fd)
{
	int error, revents, pwake = 0;
	unsigned long flags;
	long user_watches;
	struct epitem *epi;
	struct ep_pqueue epq;

	//是否到达最大的监听数
	user_watches = atomic_long_read(&ep->user->epoll_watches);
	if (unlikely(user_watches >= max_user_watches))
		return -ENOSPC;
	if (!(epi = kmem_cache_alloc(epi_cache, GFP_KERNEL))) //最有意思的地方 slab机制,在缓存中分配对象,为了更快的访问
		return -ENOMEM;

	/* Item initialization follow here ... */ //正如内核注释所言 正常的初始化
	INIT_LIST_HEAD(&epi->rdllink);
	INIT_LIST_HEAD(&epi->fllink);
	INIT_LIST_HEAD(&epi->pwqlist);
	epi->ep = ep;
	ep_set_ffd(&epi->ffd, tfile, fd);
	epi->event = *event;
	epi->nwait = 0;
	epi->next = EP_UNACTIVE_PTR;

	/* Initialize the poll table using the queue callback */
	epq.epi = epi;
	//设置poll的回调为ep_ptable_queue_proc,这其中藏着epoll如此高效的原因!
	init_poll_funcptr(&epq.pt, ep_ptable_queue_proc);

	/*
	 * Attach the item to the poll hooks and get current event bits.
	 * We can safely use the file* here because its usage count has
	 * been increased by the caller of this function. Note that after
	 * this operation completes, the poll callback can start hitting
	 * the new item.
	 */
	//进行完这一步 算是把epitem和这个fd连接起来了 会在事件到来的时候执行上面注册的回调
	revents = tfile->f_op->poll(tfile, &epq.pt);

	/*
	 * We have to check if something went wrong during the poll wait queue
	 * install process. Namely an allocation for a wait queue failed due
	 * high memory pressure.
	 */
	error = -ENOMEM;
	if (epi->nwait < 0)
		goto error_unregister;

	/* Add the current item to the list of active epoll hook for this file */
	spin_lock(&tfile->f_lock); //tfile是要加入的fd的file指针
	list_add_tail(&epi->fllink, &tfile->f_ep_links); //file会把监听自己的epitem连接起来
	spin_unlock(&tfile->f_lock);

	/*
	 * Add the current item to the RB tree. All RB tree operations are
	 * protected by "mtx", and ep_insert() is called with "mtx" held.
	 */
	ep_rbtree_insert(ep, epi); //向ep的红黑树中插入一个epitem

	/* We have to drop the new item inside our item list to keep track of it */
	spin_lock_irqsave(&ep->lock, flags);

	/* If the file is already "ready" we drop it inside the ready list */
	//这里处理的是监听的fd刚好有事件发生,如果现在不处理,可能后面不会到来数据,也就刽触发回调,它们可能就再也不会被处理了
	if ((revents & event->events) && !ep_is_linked(&epi->rdllink)) {
		list_add_tail(&epi->rdllink, &ep->rdllist);

		/* Notify waiting tasks that events are available */
		if (waitqueue_active(&ep->wq))
			wake_up_locked(&ep->wq); //唤醒epoll_wait中的等待队列
		if (waitqueue_active(&ep->poll_wait))
			pwake++;
	}

	spin_unlock_irqrestore(&ep->lock, flags);

	atomic_long_inc(&ep->user->epoll_watches);

	/* We have to call this outside the lock */
	if (pwake)
		ep_poll_safewake(&ep->poll_wait);

	return 0;

error_unregister:
	ep_unregister_pollwait(ep, epi);

	/*
	 * We need to do this because an event could have been arrived on some
	 * allocated wait queue. Note that we don't care about the ep->ovflist
	 * list, since that is used/cleaned only inside a section bound by "mtx".
	 * And ep_insert() is called with "mtx" held.
	 */
	spin_lock_irqsave(&ep->lock, flags);
	if (ep_is_linked(&epi->rdllink))
		list_del_init(&epi->rdllink);
	spin_unlock_irqrestore(&ep->lock, flags);

	kmem_cache_free(epi_cache, epi);

	return error;
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
static void ep_ptable_queue_proc(struct file *file, wait_queue_head_t *whead,
				 poll_table *pt)
{
	struct epitem *epi = ep_item_from_epqueue(pt);
	struct eppoll_entry *pwq;
/*

struct eppoll_entry { //这个结构体就是做一个epitem和其回调之间的关联
	// List header used to link this structure to the "struct epitem"
	struct list_head llink;

	// The "base" pointer is set to the container "struct epitem"
	struct epitem *base;

	 //Wait queue item that will be linked to the target file wait
	 //queue head.
	wait_queue_t wait;

	// The wait queue head that linked the "wait" wait queue item
	wait_queue_head_t *whead;
};

*/
	if (epi->nwait >= 0 && (pwq = kmem_cache_alloc(pwq_cache, GFP_KERNEL))) {
		//初始化一个等待队列的节点 其中注册的回调为ep_poll_callback
		init_waitqueue_func_entry(&pwq->wait, ep_poll_callback);
		pwq->whead = whead;  //这个就是监控的fd的等待队列头
		pwq->base = epi;
		add_wait_queue(whead, &pwq->wait);//把初始化的等待对列头插入到所监控的fd的等待对列中,稍后调用
		list_add_tail(&pwq->llink, &epi->pwqlist);
		epi->nwait++;//记录了poll执行回调的次数,即数据来了几次
	} else {
		/* We have to signal that an error occurred */
		epi->nwait = -1;
	}
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
static int ep_poll_callback(wait_queue_t *wait, unsigned mode, int sync, void *key) //key是events
{
	int pwake = 0;
	unsigned long flags;
	struct epitem *epi = ep_item_from_wait(wait); //由等待队列中获取对应的epitem
	struct eventpoll *ep = epi->ep; //从而得到epoll的结构

	spin_lock_irqsave(&ep->lock, flags); //这里要操作rdllist 上锁

	/*
	 * If the event mask does not contain any poll(2) event, we consider the
	 * descriptor to be disabled. This condition is likely the effect of the
	 * EPOLLONESHOT bit that disables the descriptor when an event is received,
	 * until the next EPOLL_CTL_MOD will be issued.
	 */
	 //#define EP_PRIVATE_BITS (EPOLLONESHOT | EPOLLET)
	if (!(epi->event.events & ~EP_PRIVATE_BITS)) //我们看到如果所监控的fd没有注册什么事件的话,就不加入rdllist中
		goto out_unlock;

	/*
	 * Check the events coming with the callback. At this stage, not
	 * every device reports the events in the "key" parameter of the
	 * callback. We need to be able to handle both cases here, hence the
	 * test for "key" != NULL before the event match test.
	 */
	if (key && !((unsigned long) key & epi->event.events)) //所触发的事件我们没有注册的话当然也不加入rdllist中
		goto out_unlock;

	/*
	 * If we are trasfering events to userspace, we can hold no locks
	 * (because we're accessing user memory, and because of linux f_op->poll()
	 * semantics). All the events that happens during that period of time are
	 * chained in ep->ovflist and requeued later on.
	 */
	 /*
	  * 这里就比较有意思了
	  * 在epoll_wait中EP_UNACTIVE_PTR初始化为EP_UNACTIVE_PTR,而当epoll_wait]中被唤醒后处理rdlist时会将ep->ovflist置为NULL
	  * 也就是说如果ep->ovflist != EP_UNACTIVE_PTR意味这epoll_wait已被唤醒 正在执行loop
	  * 此时我们就把在rdllist遍历时发生的事件用ovflist串起来,在遍历结束后插入rdllist中
	  */
	if (unlikely(ep->ovflist != EP_UNACTIVE_PTR)) {
		if (epi->next == EP_UNACTIVE_PTR) {
			epi->next = ep->ovflist;
			ep->ovflist = epi;
		}
		goto out_unlock;
	}

	/* If this file is already in the ready list we exit soon */
	//将当前的epitem加入到rdllist中
	//这就是epoll如此高效的原因,我们不必每次去遍历fd寻找触发的事件,触发事件时会触发回调自动把epitem加入到rdllist中,
	//这使得复杂度从O(N)降到了O(有效事件集合),且我们不必每次注册事件,仅在epoll_ctl(ADD)中注册一次即可(修改除外),
	if (!ep_is_linked(&epi->rdllink))
		list_add_tail(&epi->rdllink, &ep->rdllist);

	/*
	 * Wake up ( if active ) both the eventpoll wait list and the ->poll()
	 * wait list.
	 */
	 //唤醒epoll_wait
	if (waitqueue_active(&ep->wq))
		wake_up_locked(&ep->wq);
	if (waitqueue_active(&ep->poll_wait))
		pwake++;

out_unlock:
	spin_unlock_irqrestore(&ep->lock, flags);

	/* We have to call this outside the lock */
	if (pwake)
		ep_poll_safewake(&ep->poll_wait);

	return 1;
}
