//03_Wire.v
module top_module( input in, output out );
assign out = in;
endmodule


//04_Wire4.v
module top_module(
    input a,b,c,
    output w,x,y,z );
    assign w = a;
    assign x = b;
    assign y = b;
    assign z = c;
endmodule

//05_Inverter.v
module top_module( input in, output out );
    assign out = ~in;
endmodule


//06_Andgate.v
module top_module(
    input a,
    input b,
    output out );
    assign out = a & b;
endmodule


//07_Norgate.v
module top_module(
    input a,
    input b,
    output out );
    assign out = ~(a | b);
endmodule


//08_Xnorgate.v
module top_module(
    input a,
    input b,
    output out );
    assign out = ~(a ^ b);
endmodule


//09_Wire_decl.v
`default_nettype none
module top_module(
    input a,
    input b,
    input c,
    input d,
    output out,
    output out_n   );

    wire wire1, wire2, wire3;
    assign wire1 = a & b;
    assign wire2 = c & d;
    assign wire3 = wire1 | wire2;
    assign out = wire3;
    assign out_n = ~wire3;

endmodule


//10_7458.v
module top_module (
    input p1a, p1b, p1c, p1d, p1e, p1f,
    output p1y,
    input p2a, p2b, p2c, p2d,
    output p2y );

    wire abc1, def1, ab2, cd2;
    assign abc1 = p1c & p1b & p1a;
    assign def1 = p1f & p1e & p1d;
    assign p1y = abc1 | def1;

    assign ab2 = p2a & p2b;
    assign cd2 = p2c & p2d;
    assign p2y = ab2 | cd2;

endmodule


//11_Vector0.v
module top_module (
    input wire [2:0] vec,
    output wire [2:0] outv,
    output wire o2,
    output wire o1,
    output wire o0  ); // Module body starts after module declaration

    assign outv = vec;
    assign o0 = outv[0];
    assign o1 = outv[1];
    assign o2 = outv[2];

endmodule


//12_7Vector1.v
`default_nettype none     // Disable implicit nets. Reduces some types of bugs.
module top_module(
    input wire [15:0] in,
    output wire [7:0] out_hi,
    output wire [7:0] out_lo );

    assign out_hi = in[15:8];
    assign out_lo = in[7:0];

endmodule


//13_Vector2.v
module top_module(
    input [31:0] in,
    output [31:0] out );//

    // assign out[31:24] = ...;
    assign out = {in[7:0], in[15:8], in[23:16], in[31:24]};

endmodule


//14_Vectorgates.v
module top_module(
    input [2:0] a,
    input [2:0] b,
    output [2:0] out_or_bitwise,
    output out_or_logical,
    output [5:0] out_not
);

    assign out_or_bitwise = a | b;
    assign out_or_logical = a || b;
    assign out_not[5:3] = ~b;
    assign out_not[2:0] = ~a;

endmodule


//15_Gates4.v
module top_module(
    input [3:0] in,
    output out_and,
    output out_or,
    output out_xor
);

    assign out_and = in[0] & in[1] & in[2] & in[3];
    assign out_or = in[0] | in[1] | in[2] | in[3];
    assign out_xor = in[0] ^ in[1] ^ in[2] ^ in[3];

endmodule


//16_Vector3.v
module top_module (
    input [4:0] a, b, c, d, e, f,
    output [7:0] w, x, y, z );//

    // assign { ... } = { ... };
    // assign {w[7:0], x[7:0], y[7:0], z[7:0]} = {a[4:0], b[4:0], c[4:0], d[4:0], e[4:0], f[4:0], 2'b11};
    assign {w, x, y, z} = {a, b, c, d, e, f, 2'b11};

endmodule


//17_Vectorr.v
module top_module(
    input [7:0] in,
    output [7:0] out
);
    assign out = {in[0], in[1], in[2], in[3], in[4], in[5], in[6], in[7]};
endmodule


//18_Vector4.v
module top_module (
    input [7:0] in,
    output [31:0] out );//

    // assign out = { replicate-sign-bit , the-input };
    assign out = {{24{in[7]}}, in};

endmodule


//19_Vector5.v
module top_module (
    input a, b, c, d, e,
    output [24:0] out );//

    assign out[24:20] = ~ {5{a}} ^ {a, b, c, d, e};
    assign out[19:15] = ~ {5{b}} ^ {a, b, c, d, e};
    assign out[14:10] = ~ {5{c}} ^ {a, b, c, d, e};
    assign out[9:5] = ~ {5{d}} ^ {a, b, c, d, e};
    assign out[4:0] = ~ {5{e}} ^ {a, b, c, d, e};

endmodule


//20_Module.v
module top_module ( input a, input b, output out );
    mod_a instance1(.out(out), .in1(a), .in2(b));
endmodule


//21_Module_pos.v
module top_module (
    input a,
    input b,
    input c,
    input d,
    output out1,
    output out2
);
    mod_a instance1(out1, out2, a, b, c, d);
endmodule


//22_Module_name.v
module top_module (
    input a,
    input b,
    input c,
    input d,
    output out1,
    output out2
);
    mod_a instance1(.in1(a), .in2(b), .in3(c), .in4(d), .out1(out1), .out2(out2),);
endmodule


//23_Module_shift.v
module top_module ( input clk, input d, output q );
    wire q1, q2;
    my_dff instance1(.clk(clk), .d(d), .q(q1));
    my_dff instance2(.clk(clk), .d(q1), .q(q2));
    my_dff instance3(.clk(clk), .d(q2), .q(q));
endmodule


//24_Module_shift8v.v
module top_module (
    input clk,
    input [7:0] d,
    input [1:0] sel,
    output [7:0] q
);

    wire [7:0] q1, q2, q3;
    my_dff8 instance1(.clk(clk), .d(d), .q(q1));
    my_dff8 instance2(.clk(clk), .d(q1), .q(q2));
    my_dff8 instance3(.clk(clk), .d(q2), .q(q3));

    always @(*) begin
        case(sel)
            0 : q = d;
            1 : q = q1;
            2 : q = q2;
            3 : q = q3;
        endcase
    end

endmodule


//25_Module_add.v
module top_module(
    input [31:0] a,
    input [31:0] b,
    output [31:0] sum
);

    wire cin1, cout1,cout2;
    wire [15:0] sum1, sum2;
    assign cin1 = 0;

    add16 instance1(.a(a[15:0]), .b(b[15:0]), .cin(cin1), .cout(cout1), .sum(sum1));
    add16 instance2(.a(a[31:16]), .b(b[31:16]), .cin(cout1), .cout(cout2), .sum(sum2));

    assign sum = {sum2, sum1};

endmodule


//26_Module_fadd.v
module top_module (
    input [31:0] a,
    input [31:0] b,
    output [31:0] sum
);//
    wire cin1, cout1, cout2;
    wire [15:0] sum1, sum2;
    assign cin1 = 0;
    add16 instance1(.a(a[15:0]), .b(b[15:0]), .cin(cin1), .cout(cout1), .sum(sum1));
    add16 instance2(.a(a[31:16]), .b(b[31:16]), .cin(cout1), .cout(cout2), .sum(sum2));

    assign sum = {sum2, sum1};

endmodule

module add1 ( input a, input b, input cin,   output sum, output cout );

// Full adder module here
    always @(*) begin
        if(!cin) begin
            if(a == 0 && b == 0) begin
                sum = 0;
                cout = 0;
            end
            else if((a == 0 && b == 1) || (a == 1 && b == 0)) begin
                sum = 1;
                cout = 0;
            end
            else begin
                sum = 0;
                cout = 1;
            end
        end
        else begin
            if(a == 0 && b == 0) begin
                sum = 1;
                cout = 0;
            end
            else if((a == 0 && b == 1) || (a == 1 && b == 0)) begin
                sum = 0;
                cout = 1;
            end
            else begin
                sum = 1;
                cout = 1;
            end
        end
    end

endmodule


//27_Module_cseladd.v
module top_module(
    input [31:0] a,
    input [31:0] b,
    output [31:0] sum
);

    wire cin1, cout1, cin2, cout2, cin3, cout3;
    wire [15:0] sum1, sum2, sum3, sum_h;
    assign cin1 = 0;
    assign cin2 = 0;
    assign cin3 = 1;

    add16 instance1(.a(a[15:0]), .b(b[15:0]), .cin(cin1), .cout(cout1), .sum(sum1));
    add16 instance2(.a(a[31:16]), .b(b[31:16]), .cin(cin2), .cout(cout2), .sum(sum2));
    add16 instance3(.a(a[31:16]), .b(b[31:16]), .cin(cin3), .cout(cout3), .sum(sum3));

    always @(*) begin
        case(cout1)
            0 : sum_h = sum2;
            1 : sum_h = sum3;
        endcase
    end

    assign sum = {sum_h, sum1};

endmodule


//28_Module_addsub.v
module top_module(
    input [31:0] a,
    input [31:0] b,
    input sub,
    output [31:0] result
);

    wire cout1, cout2;
    wire [15:0] sum1, sum2;
    wire [31:0] b_xor;

    always @(*) begin
        if(sub)
            b_xor = ~b;
        else
            b_xor = b;
    end

    add16 instance1(.a(a[15:0]), .b(b_xor[15:0]), .cin(sub), .cout(cout1), .sum(sum1));
    add16 instance2(.a(a[31:16]), .b(b_xor[31:16]), .cin(cout1), .cout(cout2), .sum(sum2));

    assign result = {sum2, sum1};

endmodule


//29_Alwaysblock1.v
// synthesis verilog_input_version verilog_2001
module top_module(
    input a,
    input b,
    output wire out_assign,
    output reg out_alwaysblock
);

    assign out_assign = a & b;
    always @(*) out_alwaysblock = a & b;

endmodule


//30_Alwaysblock2.v
// synthesis verilog_input_version verilog_2001
module top_module(
    input clk,
    input a,
    input b,
    output wire out_assign,
    output reg out_always_comb,
    output reg out_always_ff   );

    assign out_assign = a ^ b;
    always @(*) out_always_comb = a ^ b;
    always @(posedge clk) out_always_ff <= a ^ b;

endmodule


//31_Always if.v
// synthesis verilog_input_version verilog_2001
module top_module(
    input a,
    input b,
    input sel_b1,
    input sel_b2,
    output wire out_assign,
    output reg out_always   );

    assign out_assign = (sel_b1 && sel_b2) ? b : a;
    always @(*) out_always = (sel_b1 && sel_b2) ? b : a;

endmodule


//32_Always if2.v
// synthesis verilog_input_version verilog_2001
module top_module (
    input      cpu_overheated,
    output reg shut_off_computer,
    input      arrived,
    input      gas_tank_empty,
    output reg keep_driving  ); //

    always @(*) begin
        if (cpu_overheated)
           shut_off_computer = 1;
        else
            shut_off_computer = 0;
    end

    always @(*) begin
        if (~arrived)
            keep_driving = ~gas_tank_empty;
        else
            keep_driving = 0;
    end

endmodule


//33_Always_case.v
// synthesis verilog_input_version verilog_2001
module top_module (
    input [2:0] sel,
    input [3:0] data0,
    input [3:0] data1,
    input [3:0] data2,
    input [3:0] data3,
    input [3:0] data4,
    input [3:0] data5,
    output reg [3:0] out   );//

    always@(*) begin  // This is a combinational circuit
        case(sel)
            0 : out = data0;
            1 : out = data1;
            2 : out = data2;
            3 : out = data3;
            4 : out = data4;
            5 : out = data5;
            default : out = 0;
        endcase
    end

endmodule

//34 Always case2
// synthesis verilog_input_version verilog_2001
module top_module (
    input [3:0] in,
    output reg [1:0] pos  );
	integer i;
    always@(*)
        begin
            case(in)
            4'd0 : pos = 0;
            4'd1 : pos = 0;
            4'd2 : pos = 1;
            4'd3 : pos = 0;
            4'd4 : pos = 2;
            4'd5 : pos = 0;
            4'd6 : pos = 1;
            4'd7 : pos = 0;
            4'd8 : pos = 3;
            4'd9 : pos = 0;
            4'd10 : pos = 1;
            4'd11 : pos = 0;
            4'd12 : pos = 2;
            4'd13 : pos = 0;
            4'd14 : pos = 1;
            4'd15 : pos = 0;
        endcase
        end

endmodule

// 35 Always casez
// synthesis verilog_input_version verilog_2001
module top_module (
    input [7:0] in,
    output reg [2:0] pos  );
    always @ (*)
        begin
            casez(in)
                8'bzzzzzzz1: pos = 3'd0;
                8'bzzzzzz1z: pos = 3'd1;
                8'bzzzzz1zz: pos = 3'd2;
                8'bzzzz1zzz: pos = 3'd3;
                8'bzzz1zzzz: pos = 3'd4;
                8'bzz1zzzzz: pos = 3'd5;
                8'bz1zzzzzz: pos = 3'd6;
                8'b1zzzzzzz: pos = 3'd7;
                default: pos = 3'd0;

            endcase
        end
endmodule

//36 Always nolatches
// synthesis verilog_input_version verilog_2001
module top_module (
    input [15:0] scancode,
    output reg left,
    output reg down,
    output reg right,
    output reg up  );

    always@(*)
        begin
            case(scancode)
                16'he06b:
                    begin
                        left = 1;
                        down = 0;
                        right = 0;
                        up = 0;
                    end
                16'he072:
                    begin
                        left = 0;
                        down = 1;
                        right = 0;
                        up = 0;
                    end
                16'he074:
                    begin
                        left = 0;
                        down = 0;
                        right = 1;
                        up = 0;
                    end
                16'he075:
                    begin
                        left = 0;
                        down = 0;
                        right = 0;
                        up = 1;
                    end
                default:
                    begin
                        left = 0;
                        down = 0;
                        right = 0;
                        up = 0;
                    end
            endcase
        end

endmodule
