Android自定义文件路径选择器

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
package com.filebrowser;

import android.content.Context;
import android.graphics.Bitmap;
import android.graphics.BitmapFactory;
import android.view.LayoutInflater;
import android.view.View;
import android.view.ViewGroup;
import android.widget.AdapterView;
import android.widget.BaseAdapter;
import android.widget.ImageView;
import android.widget.ListView;
import android.widget.TextView;

import java.io.File;
import java.io.FileFilter;
import java.util.Arrays;
import java.util.Collections;
import java.util.Comparator;
import java.util.List;

public class MyAdapter extends BaseAdapter implements View.OnClickListener, AdapterView.OnItemClickListener {
  private String rootPath;
  private LayoutInflater mInflater;
  private Bitmap mIcon3;
  private Bitmap mIcon4;
  private List<File> fileList;
  private View header;
  private View layoutReturnRoot;
  private View layoutReturnPre;
  private TextView curPathTextView;
  private String suffix = "";
  private String currentDirPath;
  private FileSelectListener listener;

  public MyAdapter(View fileSelectListView, String rootPath, String defaultPath) {
    this.rootPath = rootPath;
    Context context = fileSelectListView.getContext();
    mInflater = LayoutInflater.from(context);
    mIcon3 = BitmapFactory.decodeResource(context.getResources(), R.drawable.icon_fodler);
    mIcon4 = BitmapFactory.decodeResource(context.getResources(), R.drawable.icon_file);

    curPathTextView = (TextView) fileSelectListView.findViewById(R.id.curPath);
    header = fileSelectListView.findViewById(R.id.layoutFileListHeader);
    layoutReturnRoot = fileSelectListView.findViewById(R.id.layoutReturnRoot);
    layoutReturnPre = fileSelectListView.findViewById(R.id.layoutReturnPre);
    layoutReturnRoot.setOnClickListener(this);
    layoutReturnPre.setOnClickListener(this);
    if (defaultPath != null && !defaultPath.isEmpty()) {
      getFileDir(defaultPath);
    } else {
      getFileDir(rootPath);
    }
    ListView listView = (ListView) fileSelectListView.findViewById(R.id.list);
    listView.setAdapter(this);
    listView.setOnItemClickListener(this);
  }

  private class ViewHolder {
    TextView text;
    ImageView icon;
  }

  public interface FileSelectListener {
    void onFileSelect(File selectedFile);

    void onDirSelect(File selectedDir);
  }

  public void setOnFileSelectListener(FileSelectListener listener) {
    this.listener = listener;
  }

  /**
   * 获取所选文件路径下的所有文件，并且更新到listview中
   */
  private void getFileDir(String filePath) {
    File file = new File(filePath);
    File[] files = file.listFiles(new FileFilter() {
      @Override
      public boolean accept(File pathname) {
        if (pathname.isFile()&&!suffix.isEmpty()){
          return pathname.getName().endsWith(suffix);
        }
        return true;
      }
    });
    fileList = Arrays.asList(files);
    //按名称排序
    Collections.sort(fileList, new Comparator<File>() {
      @Override
      public int compare(File o1, File o2) {
        if (o1.isFile() && o2.isDirectory())
          return 1;
        if (o1.isDirectory() && o2.isFile())
          return -1;
        return o1.getName().compareTo(o2.getName());
      }
    });

    if (header != null) {
      header.setVisibility(filePath.equals(rootPath) ? View.GONE : View.VISIBLE);
    }

    notifyDataSetChanged();

    if (curPathTextView != null) {
      curPathTextView.setText(filePath);
    }
    currentDirPath = filePath;

    if (listener!=null){
      listener.onDirSelect(file);
    }
  }


  public int getCount() {
    return fileList.size();
  }

  public Object getItem(int position) {
    return fileList.get(position);
  }

  public long getItemId(int position) {
    return position;
  }

  public View getView(int position, View convertView, ViewGroup parent) {
    ViewHolder holder;
    if (convertView == null) {
      convertView = mInflater.inflate(R.layout.file_item, null);
      holder = new ViewHolder();
      holder.text = (TextView) convertView.findViewById(R.id.text);
      holder.icon = (ImageView) convertView.findViewById(R.id.icon);
      convertView.setTag(holder);
    } else {
      holder = (ViewHolder) convertView.getTag();
    }

    File file = fileList.get(position);
    holder.text.setText(file.getName());
    if (file.isDirectory()) {
      holder.icon.setImageBitmap(mIcon3);
    } else {
      holder.icon.setImageBitmap(mIcon4);
    }
    return convertView;
  }

  @Override
  public void onItemClick(AdapterView<?> parent, View view, int position, long id) {
    File file = fileList.get(position);
    if (file.isDirectory()) {
      getFileDir(file.getPath());
    } else {
      if (listener!=null){
        listener.onFileSelect(file);
      }
    }
  }

  @Override
  public void onClick(View v) {
    if (v.getId() == R.id.layoutReturnRoot) {
      getFileDir(rootPath);
    } else if (v.getId() == R.id.layoutReturnPre) {
      getFileDir(new File(currentDirPath).getParent());
    }
  }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:layout_width="match_parent"
  android:background="@color/white"
  android:layout_height="wrap_content">

  <LinearLayout
    android:id="@+id/layoutFileSelectList"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    android:layout_marginTop="10dp"
    android:orientation="vertical"
    android:showDividers="middle|end">

    <TextView
      android:id="@+id/curPath"
      android:layout_width="wrap_content"
      android:layout_height="wrap_content"
      android:layout_marginBottom="6dp"
      android:paddingLeft="10dp"
      android:textSize="16sp" />

    <LinearLayout
      android:id="@+id/layoutFileListHeader"
      android:layout_width="match_parent"
      android:layout_height="wrap_content"
      android:divider="@drawable/shape_divider_line"
      android:showDividers="beginning|middle|end"
      android:orientation="vertical">

      <LinearLayout
        android:id="@+id/layoutReturnRoot"
        android:layout_width="match_parent"
        android:layout_height="50dp"
        android:paddingLeft="10dp"
        android:gravity="center"
        android:orientation="horizontal">

        <ImageView
          android:id="@+id/iv_return_root"
          android:layout_width="30dp"
          android:layout_height="30dp"
          android:background="@drawable/icon_back">

        </ImageView>

        <TextView
          android:id="@+id/tv_return_root"
          android:layout_width="0dp"
          android:layout_height="match_parent"
          android:layout_weight="1"
          android:gravity="center_vertical"
          android:paddingLeft="10dp"
          android:text="@string/ReturnRootDir"
          android:textSize="16sp">

        </TextView>

      </LinearLayout>

      <LinearLayout
        android:id="@+id/layoutReturnPre"
        android:layout_width="match_parent"
        android:layout_height="50dp"
        android:paddingLeft="10dp"
        android:gravity="center"
        android:orientation="horizontal">

        <ImageView
          android:id="@+id/iv_return_pre"
          android:layout_width="30dp"
          android:layout_height="30dp"
          android:background="@drawable/icon_back02">

        </ImageView>

        <TextView
          android:id="@+id/tv_return_pre"
          android:layout_width="0dp"
          android:layout_height="match_parent"
          android:layout_weight="1"
          android:gravity="center_vertical"
          android:paddingLeft="10dp"
          android:text="@string/ReturnPreDir"
          android:textSize="16sp">

        </TextView>

      </LinearLayout>

    </LinearLayout>


    <ListView
      android:id="@+id/list"
      android:layout_width="match_parent"
      android:layout_height="match_parent">

    </ListView>

  </LinearLayout>

</LinearLayout>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
package com.filebrowser;

import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.view.View;
import android.widget.TextView;
import java.io.File;

public class FileBrowserActivity extends Activity implements
    View.OnClickListener, MyAdapter.FileSelectListener {
  private TextView curPathTextView;
  private String rootPath = "";
  private MyAdapter listAdapter;
  //初始化进入的目录，默认目录
  private String filePath = "";

  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_file_browser_acitivity);
    initView();

    //跟目录
    rootPath = getIntent().getStringExtra("rootPath");
    //指定文件夹
    filePath = getIntent().getStringExtra("path");

    curPathTextView.setText(filePath);
    filePath = filePath.isEmpty() ? rootPath : filePath;
    View layoutFileSelectList = findViewById(R.id.layoutFileSelectList);
    listAdapter = new MyAdapter(layoutFileSelectList, rootPath, filePath);
    listAdapter.setOnFileSelectListener(this);

    findViewById(R.id.btnSure).setOnClickListener(this);
    findViewById(R.id.btnCancel).setOnClickListener(this);
  }

  @Override
  public void finish() {
    Intent intent = new Intent();
    intent.putExtra("file", filePath);
    setResult(RESULT_OK, intent);
    super.finish();
  }

  private void initView() {
    curPathTextView = (TextView) findViewById(R.id.curPath);
  }


  @Override
  public void onFileSelect(File selectedFile) {
    filePath = selectedFile.getPath();
  }

  @Override
  public void onDirSelect(File selectedDir) {
    filePath = selectedDir.getPath();
  }

  @Override
  public void onClick(View v) {
    switch (v.getId()){
      case R.id.btnSure:
        finish();
        break;
      case R.id.btnCancel:
        filePath ="";
        finish();
        break;

      default:
        break;

    }
  }

}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
  android:id="@+id/layoutProgramManagerMainView"
  android:layout_width="match_parent"
  android:layout_height="match_parent"
  android:focusable="true"
  android:focusableInTouchMode="true"
  android:orientation="vertical">

  <include
    android:layout_weight="1"
    android:layout_width="match_parent"
    android:layout_height="0dp"
    layout="@layout/layout_file_select_list"/>
  <LinearLayout
    android:layout_width="match_parent"
    android:layout_height="50dp"
    android:layout_gravity="bottom"
    android:layout_weight="0"
    android:orientation="vertical"
    android:showDividers="beginning">

    <LinearLayout
      android:layout_width="match_parent"
      android:layout_height="match_parent"
      android:gravity="center"
      android:orientation="horizontal">


      <Button
        android:id="@+id/btnCancel"
        android:layout_width="0dp"
        android:layout_height="40dp"
        android:layout_weight="1"
        android:text="@string/cancel"
        android:textSize="16sp" />
      <Button
        android:id="@+id/btnSure"
        android:layout_width="0dp"
        android:layout_height="40dp"
        android:layout_weight="1"
        android:text="@string/sure"
        android:textSize="16sp" />

    </LinearLayout>
  </LinearLayout>

</LinearLayout>

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
package com.filebrowser;

import android.app.Activity;
import android.content.Intent;
import android.os.Bundle;
import android.os.Environment;
import android.os.storage.StorageManager;
import android.view.View;
import android.widget.Button;
import android.widget.TextView;
import java.lang.reflect.InvocationTargetException;
import java.lang.reflect.Method;
import java.util.Locale;

public class MainActivity extends Activity {
  public static final int FILE_RESULT_CODE = 1;
  private Button btn_open;
  private TextView changePath;
  private String rootPath;

  @Override
  protected void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    setContentView(R.layout.activity_main);
    initView();
    initListener();
  }

  private void initView() {
    btn_open = (Button) findViewById(R.id.btn_open);
    changePath = (TextView) findViewById(R.id.changePath);
  }

  private void initListener() {
    btn_open.setOnClickListener(new View.OnClickListener() {
      @Override
      public void onClick(View view) {
        openBrowser();
      }
    });

    findViewById(R.id.btn_open1).setOnClickListener(new View.OnClickListener() {
      @Override
      public void onClick(View v) {
        openBrowser1();
      }
    });
  }

  private void openBrowser() {
    rootPath = System.getenv("SECONDARY_STORAGE");
    if (rootPath == null) {
      rootPath = Environment.getExternalStorageDirectory().toString();
    }
    if ((rootPath.equals(Environment.getExternalStorageDirectory().toString()))) {
      String filePath = rootPath + "/Android";
      Intent intent = new Intent(MainActivity.this, FileBrowserActivity.class);
      //根目录
      intent.putExtra("rootPath", rootPath);
      //进去指定文件夹
      intent.putExtra("path", filePath);
      startActivityForResult(intent, FILE_RESULT_CODE);
    }
  }

  private void openBrowser1() {
    rootPath = getSdcardPath();
    if (rootPath == null || rootPath.isEmpty()) {
      rootPath = Environment.getExternalStorageDirectory().toString();
    }
    Intent intent = new Intent(MainActivity.this, FileBrowserActivity.class);
    intent.putExtra("rootPath", rootPath);
    intent.putExtra("path", rootPath);
    startActivityForResult(intent, FILE_RESULT_CODE);
  }

  public String getSdcardPath() {
    String sdcardPath = "";
    String[] pathArr = null;
    StorageManager storageManager = (StorageManager) getSystemService(STORAGE_SERVICE);
    try {
      Method getVolumePaths = storageManager.getClass().getMethod("getVolumePaths");
      pathArr = (String[]) getVolumePaths.invoke(storageManager);
    } catch (NoSuchMethodException e) {
      e.printStackTrace();
    } catch (InvocationTargetException e) {
      e.printStackTrace();
    } catch (IllegalAccessException e) {
      e.printStackTrace();
    }
    if (pathArr != null && pathArr.length >= 3) {
      sdcardPath = pathArr[1];
    }
    return sdcardPath;
  }

  @Override
  protected void onActivityResult(int requestCode, int resultCode, Intent data) {
    if (FILE_RESULT_CODE == requestCode) {
      Bundle bundle = null;
      if (data != null && (bundle = data.getExtras()) != null) {
        String path = bundle.getString("file","");
        if(!path.isEmpty()){
          changePath.setText("选择路径为 : " + path);
        }
      }
    }
  }
}

1
2
<uses-permission android:name="android.permission.MOUNT_UNMOUNT_FILESYSTEMS" />
<uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" />
