Android实现屏幕录制功能

1
2
3
4
5
6
7
8
9
10
11
12
13
14
dependencies {
 implementation fileTree(dir: 'libs', include: ['*.jar'])
 implementation"org.jetbrains.kotlin:kotlin-stdlib-jdk7:$kotlin_version"
 implementation 'androidx.appcompat:appcompat:1.1.0'
 implementation 'androidx.core:core-ktx:1.0.2'
 implementation 'androidx.constraintlayout:constraintlayout:1.1.3'
 testImplementation 'junit:junit:4.12'
 androidTestImplementation 'androidx.test.ext:junit:1.1.1'
 androidTestImplementation 'androidx.test.espresso:espresso-core:3.2.0'
 api 'com.blankj:utilcode:1.24.4'
}
repositories {
 mavenCentral()
}

1
2
3
<uses-permission android:name="android.permission.RECORD_AUDIO" />
<uses-permission android:name="android.permission.WRITE_EXTERNAL_STORAGE" />
<uses-permission android:name="android.permission.READ_EXTERNAL_STORAGE" />

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
package com.ufi.pdioms.ztkotlin


import android.content.Intent
import android.content.res.AssetFileDescriptor
import android.media.MediaPlayer
import android.os.Build
import androidx.appcompat.app.AppCompatActivity
import android.os.Bundle
import android.util.Log
import android.widget.Toast
import com.blankj.utilcode.util.PathUtils
import kotlinx.android.synthetic.main.activity_main.*

class MainActivity : AppCompatActivity() {
 // https://github.com/fanqilongmoli/AndroidScreenRecord
 private var screenRecordHelper: ScreenRecordHelper? = null
 private val afdd:AssetFileDescriptor by lazy { assets.openFd("test.aac") }

 override fun onCreate(savedInstanceState: Bundle?) {
  super.onCreate(savedInstanceState)
  setContentView(R.layout.activity_main)

  btnStart.setOnClickListener {
   if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP) {
    if (screenRecordHelper == null) {
     screenRecordHelper = ScreenRecordHelper(this, object : ScreenRecordHelper.OnVideoRecordListener {
      override fun onBeforeRecord() {
      }

      override fun onStartRecord() {
       play()
      }

      override fun onCancelRecord() {
       releasePlayer()
      }

      override fun onEndRecord() {
       releasePlayer()
      }

     }, PathUtils.getExternalStoragePath() + "/fanqilong")
    }
    screenRecordHelper?.apply {
     if (!isRecording) {
      // 如果你想录制音频（一定会有环境音量），你可以打开下面这个限制,并且使用不带参数的 stopRecord()
//      recordAudio = true
      startRecord()
     }
    }
   } else {
    Toast.makeText(this@MainActivity.applicationContext, "sorry,your phone does not support recording screen", Toast.LENGTH_LONG).show()
   }
  }

  btnStop.setOnClickListener {
   if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP) {
    screenRecordHelper?.apply {
     if (isRecording) {
      if (mediaPlayer != null) {
       // 如果选择带参数的 stop 方法，则录制音频无效
       stopRecord(mediaPlayer!!.duration.toLong(), 15 * 1000, afdd)
      } else {
       stopRecord()
      }
     }
    }
   }
  }
 }

 private fun play() {
  mediaPlayer = MediaPlayer()
  try {
   mediaPlayer?.apply {
    this.reset()
    this.setDataSource(afdd.fileDescriptor, afdd.startOffset, afdd.length)
    this.isLooping = true
    this.prepare()
    this.start()
   }
  } catch (e: Exception) {
   Log.d("fanqilong", "播放音乐失败")
  } finally {

  }
 }

 // 音频播放
 private var mediaPlayer: MediaPlayer? = null

 private fun releasePlayer() {
  mediaPlayer?.apply {
   stop()
   release()
  }
  mediaPlayer = null
 }

 override fun onActivityResult(requestCode: Int, resultCode: Int, data: Intent?) {
  super.onActivityResult(requestCode, resultCode, data)
  if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP && data != null) {
   screenRecordHelper?.onActivityResult(requestCode, resultCode, data)
  }
 }

 override fun onDestroy() {
  if (Build.VERSION.SDK_INT >= Build.VERSION_CODES.LOLLIPOP) {
   screenRecordHelper?.clearAll()
  }
  afdd.close()
  super.onDestroy()
 }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
171
172
173
174
175
176
177
178
179
180
181
182
183
184
185
186
187
188
189
190
191
192
193
194
195
196
197
198
199
200
201
202
203
204
205
206
207
208
209
210
211
212
213
214
215
216
217
218
219
220
221
222
223
224
225
226
227
228
229
230
231
232
233
234
235
236
237
238
239
240
241
242
243
244
245
246
247
248
249
250
251
252
253
254
255
256
257
258
259
260
261
262
263
264
265
266
267
268
269
270
271
272
273
274
275
276
277
278
279
280
281
282
283
284
285
286
287
288
289
290
291
292
293
294
295
296
297
298
299
300
301
302
303
304
305
306
307
308
309
310
311
312
313
314
315
316
317
318
319
320
321
322
323
324
325
326
327
328
329
330
331
332
333
334
335
336
337
338
339
340
341
342
343
344
345
346
347
348
349
350
351
352
353
354
355
356
357
358
359
360
361
362
363
364
365
366
367
368
369
package com.ufi.pdioms.ztkotlin

import android.app.Activity
import android.content.Context
import android.content.Intent
import android.content.pm.PackageManager
import android.content.res.AssetFileDescriptor
import android.hardware.display.DisplayManager
import android.hardware.display.VirtualDisplay
import android.media.*
import android.media.projection.MediaProjection
import android.media.projection.MediaProjectionManager
import android.net.Uri
import android.os.Build
import android.os.Environment
import android.os.Handler
import android.util.DisplayMetrics
import android.util.Log
import android.widget.Toast
import androidx.annotation.RequiresApi
import com.blankj.utilcode.constant.PermissionConstants
import com.blankj.utilcode.util.PermissionUtils
import java.io.File
import java.lang.Exception
import java.nio.ByteBuffer

@RequiresApi(Build.VERSION_CODES.LOLLIPOP)
class ScreenRecordHelper @JvmOverloads constructor(
 private var activity: Activity,
 private val listener: OnVideoRecordListener?,
 private var savePath: String = Environment.getExternalStorageDirectory().absolutePath + File.separator
   + "DCIM" + File.separator + "Camera",
 private val saveName: String = "record_${System.currentTimeMillis()}"
) {

 private val mediaProjectionManager by lazy { activity.getSystemService(Context.MEDIA_PROJECTION_SERVICE) as? MediaProjectionManager }
 private var mediaRecorder: MediaRecorder? = null
 private var mediaProjection: MediaProjection? = null
 private var virtualDisplay: VirtualDisplay? = null
 private val displayMetrics by lazy { DisplayMetrics() }
 private var saveFile: File? = null
 var isRecording = false
 var recordAudio = false

 init {
  activity.windowManager.defaultDisplay.getMetrics(displayMetrics)
 }

 companion object {
  private const val VIDEO_FRAME_RATE = 30
  private const val REQUEST_CODE = 1024
  private const val TAG = "ScreenRecordHelper"
 }

 fun startRecord() {
  if (mediaProjectionManager == null) {
   Log.d(TAG, "mediaProjectionManager == null，当前手机暂不支持录屏")
   showToast(R.string.phone_not_support_screen_record)
   return
  }

  PermissionUtils.permission(PermissionConstants.STORAGE, PermissionConstants.MICROPHONE)
   .callback(object : PermissionUtils.SimpleCallback {
    override fun onGranted() {
     mediaProjectionManager?.apply {
      listener?.onBeforeRecord()
      val intent = this.createScreenCaptureIntent()
      if (activity.packageManager.resolveActivity(
        intent,
        PackageManager.MATCH_DEFAULT_ONLY
       ) != null
      ) {
       activity.startActivityForResult(intent, REQUEST_CODE)
      } else {
       showToast(R.string.phone_not_support_screen_record)
      }
     }
    }

    override fun onDenied() {
     showToast(R.string.permission_denied)
    }

   }).request()
 }

 @RequiresApi(Build.VERSION_CODES.N)
 fun resume() {
  mediaRecorder?.resume()
 }

 @RequiresApi(Build.VERSION_CODES.N)
 fun pause() {
  mediaRecorder?.pause()
 }

 fun onActivityResult(requestCode: Int, resultCode: Int, data: Intent) {
  if (requestCode == REQUEST_CODE) {
   if (resultCode == Activity.RESULT_OK) {
    mediaProjection = mediaProjectionManager!!.getMediaProjection(resultCode, data)

    // 部分手机录制视频的时候 会出现弹框
    Handler().postDelayed({
     if (initRecorder()) {
      isRecording = true
      mediaRecorder?.start()
      listener?.onStartRecord()
     } else {
      showToast(R.string.phone_not_support_screen_record)
     }
    }, 150)
   } else {
    showToast(R.string.phone_not_support_screen_record)
   }
  }
 }

 fun cancelRecord(){
  stopRecord()
  saveFile?.delete()
  saveFile = null
  listener?.onCancelRecord()
 }


 fun stopRecord(videoDuration: Long = 0, audioDuration: Long = 0, afdd: AssetFileDescriptor? = null){
  stop()
  if (audioDuration != 0L && afdd != null) {
   syntheticAudio(videoDuration, audioDuration, afdd)
  } else {
   // saveFile
   if (saveFile != null) {
    val newFile = File(savePath, "$saveName.mp4")
    // 录制结束后修改后缀为 mp4
    saveFile!!.renameTo(newFile)
    refreshVideo(newFile)
   }
   saveFile = null
  }
 }


 private fun refreshVideo(newFile: File) {
  Log.d(TAG, "screen record end,file length:${newFile.length()}.")
  if (newFile.length() > 5000) {
   val intent = Intent(Intent.ACTION_MEDIA_SCANNER_SCAN_FILE)
   intent.data = Uri.fromFile(newFile)
   activity.sendBroadcast(intent)
   Log.e("TAG","refreshVideo: "+savePath)
   showToast(R.string.save_to_album_success)
  } else {
   newFile.delete()
   showToast(R.string.phone_not_support_screen_record)
   Log.d(TAG, activity.getString(R.string.record_faild))
  }
 }

 private fun stop() {
  if (isRecording) {
   isRecording = false
   try {
    mediaRecorder?.apply {
     setOnErrorListener(null)
     setOnInfoListener(null)
     setPreviewDisplay(null)
     stop()
     Log.d(TAG, "stop success")
    }
   } catch (e: Exception) {
    Log.e(TAG, "stopRecorder() error！${e.message}")
   } finally {
    mediaRecorder?.reset()
    virtualDisplay?.release()
    mediaProjection?.stop()
    listener?.onEndRecord()
   }


  }
 }

 private fun initRecorder(): Boolean {
  var result = true
  val f = File(savePath)
  if (!f.exists()) {
   f.mkdir()
  }
  saveFile = File(savePath, "$saveName.tmp")
  saveFile?.apply {
   if (exists()) {
    delete()
   }
  }
  mediaRecorder = MediaRecorder()
  val width = Math.min(displayMetrics.widthPixels, 1080)
  val height = Math.min(displayMetrics.heightPixels, 1920)
  mediaRecorder?.apply {
   if (recordAudio) {
    setAudioSource(MediaRecorder.AudioSource.MIC)
   }
   setVideoSource(MediaRecorder.VideoSource.SURFACE)
   setOutputFormat(MediaRecorder.OutputFormat.MPEG_4)
   setVideoEncoder(MediaRecorder.VideoEncoder.H264)
   if (recordAudio) {
    setAudioEncoder(MediaRecorder.AudioEncoder.AMR_NB)
   }
   setOutputFile(saveFile!!.absolutePath)
   setVideoSize(width, height)
   setVideoEncodingBitRate(8388608)
   setVideoFrameRate(VIDEO_FRAME_RATE)

   try {

    prepare()
    virtualDisplay = mediaProjection?.createVirtualDisplay(
     "MainScreen", width, height, displayMetrics.densityDpi,
     DisplayManager.VIRTUAL_DISPLAY_FLAG_AUTO_MIRROR, surface, null, null
    )
    Log.d(TAG, "initRecorder 成功")
   } catch (e: Exception) {
    Log.e(TAG, "IllegalStateException preparing MediaRecorder: ${e.message}")
    e.printStackTrace()
    result = false
   }
  }

  return result
 }


 private fun showToast(resId: Int) {
  Toast.makeText(activity.applicationContext, activity.applicationContext.getString(resId), Toast.LENGTH_SHORT)
   .show()
 }

 fun clearAll() {
  mediaRecorder?.release()
  mediaRecorder = null
  virtualDisplay?.release()
  virtualDisplay = null
  mediaProjection?.stop()
  mediaProjection = null
 }

 /**
  * https://stackoverflow.com/questions/31572067/android-how-to-mux-audio-file-and-video-file
  */
 private fun syntheticAudio(audioDuration: Long, videoDuration: Long, afdd: AssetFileDescriptor) {
  Log.d(TAG, "start syntheticAudio")
  val newFile = File(savePath, "$saveName.mp4")
  if (newFile.exists()) {
   newFile.delete()
  }
  try {
   newFile.createNewFile()
   val videoExtractor = MediaExtractor()
   videoExtractor.setDataSource(saveFile!!.absolutePath)
   val audioExtractor = MediaExtractor()
   afdd.apply {
    audioExtractor.setDataSource(fileDescriptor, startOffset, length * videoDuration / audioDuration)
   }
   val muxer = MediaMuxer(newFile.absolutePath, MediaMuxer.OutputFormat.MUXER_OUTPUT_MPEG_4)
   videoExtractor.selectTrack(0)
   val videoFormat = videoExtractor.getTrackFormat(0)
   val videoTrack = muxer.addTrack(videoFormat)

   audioExtractor.selectTrack(0)
   val audioFormat = audioExtractor.getTrackFormat(0)
   val audioTrack = muxer.addTrack(audioFormat)

   var sawEOS = false
   var frameCount = 0
   val offset = 100
   val sampleSize = 1000 * 1024
   val videoBuf = ByteBuffer.allocate(sampleSize)
   val audioBuf = ByteBuffer.allocate(sampleSize)
   val videoBufferInfo = MediaCodec.BufferInfo()
   val audioBufferInfo = MediaCodec.BufferInfo()

   videoExtractor.seekTo(0, MediaExtractor.SEEK_TO_CLOSEST_SYNC)
   audioExtractor.seekTo(0, MediaExtractor.SEEK_TO_CLOSEST_SYNC)

   muxer.start()

   // 每秒多少帧
   // 实测 OPPO R9em 垃圾手机，拿出来的没有 MediaFormat.KEY_FRAME_RATE
   val frameRate = if (videoFormat.containsKey(MediaFormat.KEY_FRAME_RATE)) {
    videoFormat.getInteger(MediaFormat.KEY_FRAME_RATE)
   } else {
    31
   }
   // 得出平均每一帧间隔多少微妙
   val videoSampleTime = 1000 * 1000 / frameRate
   while (!sawEOS) {
    videoBufferInfo.offset = offset
    videoBufferInfo.size = videoExtractor.readSampleData(videoBuf, offset)
    if (videoBufferInfo.size < 0) {
     sawEOS = true
     videoBufferInfo.size = 0
    } else {
     videoBufferInfo.presentationTimeUs += videoSampleTime
     videoBufferInfo.flags = videoExtractor.sampleFlags
     muxer.writeSampleData(videoTrack, videoBuf, videoBufferInfo)
     videoExtractor.advance()
     frameCount++
    }
   }
   var sawEOS2 = false
   var frameCount2 = 0
   while (!sawEOS2) {
    frameCount2++
    audioBufferInfo.offset = offset
    audioBufferInfo.size = audioExtractor.readSampleData(audioBuf, offset)

    if (audioBufferInfo.size < 0) {
     sawEOS2 = true
     audioBufferInfo.size = 0
    } else {
     audioBufferInfo.presentationTimeUs = audioExtractor.sampleTime
     audioBufferInfo.flags = audioExtractor.sampleFlags
     muxer.writeSampleData(audioTrack, audioBuf, audioBufferInfo)
     audioExtractor.advance()
    }
   }
   muxer.stop()
   muxer.release()
   videoExtractor.release()
   audioExtractor.release()

   // 删除无声视频文件
   saveFile?.delete()
  } catch (e: Exception) {
   Log.e(TAG, "Mixer Error:${e.message}")
   // 视频添加音频合成失败，直接保存视频
   saveFile?.renameTo(newFile)

  } finally {
   afdd.close()
   Handler().post {
    refreshVideo(newFile)
    saveFile = null
   }
  }
 }


 interface OnVideoRecordListener {

  /**
   * 录制开始时隐藏不必要的UI
   */
  fun onBeforeRecord()

  /**
   * 开始录制
   */
  fun onStartRecord()

  /**
   * 取消录制
   */
  fun onCancelRecord()

  /**
   * 结束录制
   */
  fun onEndRecord()
 }
}

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
<?xml version="1.0" encoding="utf-8"?>
<LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
 xmlns:app="http://schemas.android.com/apk/res-auto"
 xmlns:tools="http://schemas.android.com/tools"
 android:layout_width="match_parent"
 android:layout_height="match_parent"
 android:orientation="vertical"
 tools:context=".MainActivity">

 <Button android:id="@+id/btnStart"
  android:layout_width="match_parent"
  android:layout_height="wrap_content"
  android:textAllCaps="false"
  android:text="start"/>

 <Button android:id="@+id/btnStop"
  android:layout_width="match_parent"
  android:layout_height="wrap_content"
  android:textAllCaps="false"
  android:text="stop"/>


</LinearLayout>
