1、Half adder

Create a half adder. A half adder adds two bits (with no carry-in) and produces a sum and carry-out.

1
2
3
4
5
6
7
module top_module(
    input a, b,
    output cout, sum );
	assign cout = a & b;
    assign sum 	= a ^ b;
endmodule

2、Full adder

Create a full adder. A full adder adds three bits (including carry-in) and produces a sum and carry-out.

1
2
3
4
5
6
7
module top_module(
    input a, b, cin,
    output cout, sum );
    assign cout = (a&b) | (a&cin) | (b&cin);
    assign sum = a ^ b ^ cin;
endmodule

3、3-bit binary adder

Now that you know how to build a full adder, make 3 instances of it to create a 3-bit binary ripple-carry adder. The adder adds two 3-bit numbers and a carry-in to produce a 3-bit sum and carry out. To encourage you to actually instantiate full adders, also output the carry-out from each full adder in the ripple-carry adder. cout[2] is the final carry-out from the last full adder, and is the carry-out you usually see.

1
2
3
4
5
6
7
8
9
10
module top_module(
    input [2:0] a, b,
    input cin,
    output [2:0] cout,
    output [2:0] sum );
    assign {cout[0],sum[0]} = a[0] + b[0] + cin;
    assign {cout[1],sum[1]} = a[1] + b[1] + cout[0];
    assign {cout[2],sum[2]} = a[2] + b[2] + cout[1];
endmodule

4、Adder

1
2
3
4
5
6
7
8
9
10
11
12
module top_module (
    input [3:0] x,
    input [3:0] y,
    output [4:0] sum);

    wire cout[2:0];
    assign {cout[0],sum[0]} 	= 	x[0] + y[0];
    assign {cout[1],sum[1]} 	= 	x[1] + y[1] + cout[0];
    assign {cout[2],sum[2]} 	= 	x[2] + y[2] + cout[1];
    assign {sum[4] ,sum[3]} 	= 	x[3] + y[3] + cout[2];
endmodule

5、Signed addition overflow

Assume that you have two 8-bit 2’s complement numbers, a[7:0] and b[7:0]. These numbers are added to produce s[7:0]. Also compute whether a (signed) overflow has occurred.
A signed overflow occurs when adding two positive numbers produces a negative result, or adding two negative numbers produces a positive result. There are several methods to detect overflow: It could be computed by comparing the signs of the input and output numbers, or derived from the carry-out of bit n and n-1.

a、b分别两个数的符号位,c为运算结果符号位。
当a =b =0（两数同为正）,而c=1(结果为负)时，负溢出；
当a =b =1（两数同为负）,而c=0(结果为正)时，正溢出.

1
2
3
4
5
6
7
8
9
10
11
12
module top_module (
    input [7:0] a,
    input [7:0] b,
    output [7:0] s,
    output overflow
); //

    assign s = a + b;
    assign overflow = (a[7]&b[7]&(~s[7])) | ((~a[7])&(~b[7])&s[7]);

endmodule

6、100-bit binary adder

Create a 100-bit binary adder. The adder adds two 100-bit numbers and a carry-in to produce a 100-bit sum and carry out.

1
2
3
4
5
6
7
8
module top_module(
    input [99:0] a, b,
    input cin,
    output cout,
    output [99:0] sum );
    assign {cout,sum[99:0]} = a + b + cin;
endmodule

7、4-digit BCD adder

You are provided with a BCD (binary-coded decimal) one-digit adder named bcd_fadd that adds two BCD digits and carry-in, and produces a sum and carry-out.
module bcd_fadd {
input [3:0] a,
input [3:0] b,
input cin,
output cout,
output [3:0] sum );
Instantiate 4 copies of bcd_fadd to create a 4-digit BCD ripple-carry adder. Your adder should add two 4-digit BCD numbers (packed into 16-bit vectors) and a carry-in to produce a 4-digit sum and carry out.

1
2
3
4
5
6
7
8
9
10
11
12
13
module top_module(
    input [15:0] a, b,
    input cin,
    output cout,
    output [15:0] sum );

    wire [2:0] cinout;
    bcd_fadd a1 (a[3:0],		b[3:0],		cin,		cinout[0],	sum[3:0]);
    bcd_fadd a2 (a[7:4],		b[7:4],		cinout[0],	cinout[1],	sum[7:4]);
    bcd_fadd a3 (a[11:8],		b[11:8],	cinout[1],	cinout[2],	sum[11:8]);
    bcd_fadd a4 (a[15:12],		b[15:12],	cinout[2],	cout,		sum[15:12]);
endmodule

参考资料：https://hdlbits.01xz.net/
